High Efficiency Water Cooling Manifold System with Balanced Cooling, Individual Flow Control per Cavity, and Thermal Imaging Verification
| Place of Origin | Xiamen, Fujian, China |
|---|---|
| Brand Name | Creator |
| Certification | ISO 9001:2015 |
| Model Number | KD-FLOW-001 |
| Minimum Order Quantity | 100 Pieces |
| Price | Negotiation |
| Packaging Details | Export-grade carton with PE bag, palletized for container shipment |
| Delivery Time | 25-35 working days for new mold, 7-15 days for production |
| Payment Terms | T/T, L/C, PayPal, Western Union |
| Supply Ability | 100000 Pieces per Month |
Product Details
| Technology | Balanced Cooling Manifold | Flow Control | Individual Per Cavity |
|---|---|---|---|
| Verification | Thermal Imaging | ||
| Highlight | Balanced Cooling Manifold Water Cooling Manifold System,Individual Flow Control per Cavity Cooling Manifold,Thermal Imaging Verification Multi Cavity Cooling System |
||
Product Description
High Efficiency Water Cooling Manifold System for Multi Cavity Injection Mold Temperature Uniformity Control
Ensure consistent part quality across every cavity with Xiamen Creator Technology Co., Ltd.'s advanced water cooling manifold systems. Our multi-cavity molds feature individually balanced cooling circuits with flow meters, temperature sensors, and precision manifolds that deliver uniform cooling to each cavity, eliminating cavity-to-cavity quality variation in high-volume production.
Key Features & Advantages
- Individually balanced cooling circuits for each cavity
- In-line flow meters and temperature sensors per circuit
- Precision-machined cooling manifolds with O-ring sealed connections
- Quick-connect fittings for fast mold change and maintenance
- Real-time cooling performance monitoring capability
- Uniform cavity temperature verified with thermal imaging
Technical Specifications
| Technology | Balanced Multi-Circuit Cooling Manifold |
| Cooling Circuits | 1 per cavity + dedicated core/cavity circuits |
| Flow Control | Individual Flow Meter + Regulator per Circuit |
| Connection | Quick-Connect with O-Ring Seal |
| Monitoring | Temperature Sensors + Flow Indication |
| Cooling Medium | Water (Chilled/Tempered) |
| Verification | Thermal Imaging + Multi-Point Thermocouple |
| Application | Multi-Cavity Molds, High-Volume Production |
Manufacturing Excellence
Since 2007, our cooling system design philosophy prioritizes temperature uniformity across all cavities. We use Moldflow cooling analysis to optimize circuit layout, then machine precision cooling manifolds with individual flow control for each circuit. During mold trials, we verify temperature uniformity using thermal imaging and multi-point thermocouple measurements, ensuring every cavity produces identical quality parts.
Frequently Asked Questions
Q: How do you ensure all cavities produce identical parts?
A: We design individually balanced cooling circuits with flow meters and temperature sensors for each cavity, verified with thermal imaging during mold trials.
Q: What is the benefit of individual flow control?
A: Individual flow control allows us to fine-tune cooling for each cavity, compensating for any flow variations and ensuring uniform part temperature and quality.
Q: Do you use quick-connect fittings?
A: Yes. Our molds feature quick-connect cooling fittings for fast mold installation and changeover, reducing production downtime.
Q: Can you retrofit improved cooling to existing molds?
A: Yes. We can analyze existing molds and retrofit improved cooling manifolds, flow controls, and optimized circuits to enhance cooling performance and part quality.
